1.They can be easily equipped with various attachments and enabling them to handle a wide range of tasks including loading, unloading, digging, drilling, and cleaning.
2.Small size allows them to access areas that larger machinery cannot reach, and they are also easy to transport and store.
Color can be customized.
Product details:
項目 | 明細 | 參數 | |
整 機 性 能Specifications | 額定載荷Rated operating capacity(kg) | 380 | |
傾翻載荷Tipping load(kg) | 760 | ||
鏟斗容量Bucket capacity(m3) | 0.2 | ||
機器操縱質量Operationg weight(kg) | 1260 | ||
行駛速度Max. travel speed(km/h) | 9 | ||
工作流量Hydraulic pump flow(L/min) | 50 | ||
油箱容量Fuel tank capacity(L) | 28 | ||
輪胎型號Tires | 560*155實心輪胎 | ||
整車尺寸Overall dimensions(mm) | 2580*900*1820 | ||
整機參數Dimensions | 最大操作高度Height at maximum extension(mm) | 3600 | |
鉸接銷高度Height to bucket hinge pin(mm) | 2470 | ||
帶斗寬度Width with bucket(mm) | 900 | ||
輪距Track width(mm) | 785 | ||
軸距Wheelbase(mm) | 801 | ||
離地高度Ground clearance(mm) | 145 | ||
傾倒角Dump angle | 40° | ||
傾倒高度Dumping height(mm) | 1900 | ||
傾倒前伸Maximum reach(mm) | 441 | ||
接近角Rollback at ground | 26° | ||
離去角Angle of departure | 20° | ||
發動機Engine | 型號Maker/Model | /帕金斯/403J/18.4KW 久保田D1105/18.2KW | |
功率轉速Net power | 25hp/2800rpm | ||
可選裝 | 發動機、液壓系統(泵、閥、馬達)、輪胎、油漆顏色 |
